• Saves your battery power for when you really need it: during power cuts.
• Protect the UPS in harsh environments.
• Multiple units can be placed in parallel to meet power capacity and redundancy requirements
• Verifies UPS performance before you connect your load, without the need for a load bank.
• Including the input, output, and bypass breakers, as well as the Emergency Power Off (EPO) switch, simplifies installation planning and speeds up deployment.
• Provides proactive power and environmental management via web and/or SNMP
• The intuitive graphical user interface allows for easy system configuration.
• Simplifies installation and UPS maintenance while minimizing space requirements.
• Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection.
Specifications
• Output power capacity: 20.0kWatts / 20.0kVA
• Nominal Output Voltage: 400V 3PH
• Nominal Input Voltage: 400V 3PH
• Maximum Input Current: 37.0A
• Output Voltage Distortion: Less than 3 %
• Output Frequency (sync to mains): 50 Hz Sync to mains, 60 Hz Sync to mains
• Other Output Voltages: 380 V, 415 V
• Input frequency: 45 - 65 Hz
• Input voltage range for main operations: 304 - 477V
• Battery type: VRLA
• Interface Port(s): E3S_Parallel, E3S_TempSensor
